NVR recorder 16ch-8POE (S3013)

Specificatie’s  Q-SEE HD-NVR QT8516

Bestelnummer

S3013

Model

QT8516 8xPOE

Systeem

Compression format

H.264/MPEG-4

CPU

Corte*A9 Dual Core

OS

Embedded Linux

4MP@15fps

Video uitgang

VGA* 1:1080P (1920*1080)

HDMI* 1:1080P (1920*1080)

IP ingang

1080P

16 camera’s@30 frames/sec

720P

16 camera’s@30 frames/sec

D1

16 camera’s@30 frames/sec

Audio

Ingang

RCA X1

Uitgang

RCA X1

Opnemen

Resolutie

1080P (1920*1080

720P (1280*720)

Frame rate

PAL  1-25 frame/sec/cam

Bit rate

256Kbps-12Mbps

Coderen

CBR/VBR

Quality

6 levels

Mode

Manual, Timer, Motion, Sensor

File manager

Lock, Unlock, Reserving time

Afspelen

Playback

4CH

Search

Time/calendar/event/motion

Function

Play, Pause, FF, FB, Digital zoom

Alarm

Mode

Sensor, Motion, Video loss

Netwerk

Interface

RJ45*1

POE

RJ45*8

Protocol

TCP/IP, UDP, DHCP, DNS, PPPOE, DDNS

Others

18 users online, dual stream

Mobiel telefoon

OS

iPhone, Blackberry, Android, Windows phone

Funtion

Multi screen, Record, PTZ control,

Poort

HDD

1x SATA 6TB max

RS485

RS485 x1

USB

USB 2.0, 1x for mouse, 1x for backup device

Overige

Afstandsbediening

Ja

Power supply

AC 220-240 volt

Afmetingen

B 300mm, D 270mm, H 65 mm

Gewicht Excel. HDD

1,5 kg

Afmetingen verpakking

L 400 mm, B 330 mm, H 130 mm

Gewicht Incl. verpakking

3,1 KG

Werk omgeving

0-50 C,  10%-90% Humidity

Garantie

3 jaar
